EVSE Tester

The charging station tester is designed for testing electric vehicle AC (AC) charging equipment in MODE2 and MODE3 operating modes. This device is intended for professional use by certified professionals. The tester is an indispensable helper for charging station installation and maintenance teams and will also benefit professionals repairing MODE2 portable electric car chargers. Its functionality makes it suitable for use in electric car service stations.

Basic Settings:

• Connection Types: TYPE1 and TYPE2.
• Operating Voltage: 400V.
• Current Testing: adjustable to 6, 13, 20, or 32A.
• External Load Connection: L1 up to 5A (1kW).
• Integrated Voltmeter: allows monitoring L1, L2, L3 voltages for three-phase testing or L1 voltage for single-phase test devices.
• Signal Control: CP and PP signal testing using corresponding sockets and a multimeter.
• Insulation and Ground Circuit Testing: possible using L1, L2, L3, N, PE, and optional equipment.

The EVSE Tester is an essential tool for maintaining and testing charging equipment, providing accuracy and reliability for professional applications.
