Charging station Vertica

Enelion Vertica is designed for use in public and commercial spaces, providing reliable and aesthetically pleasing EV charging.

Main Parameters

• Charging Power: from 1.4 kW to 22 kW per port.
• Connectors:
  • Two Type 2 connectors (in the socket version).
  • Two built-in cables with Type 2 connectors up to 4 meters long (in the cable version).
• Communication and Control:
  • Support for OCPP 1.6 protocol via the Enelion Bridge module.
  • Connection options: offline, Wi-Fi, Ethernet, optionally LTE (GSM).
  • Minimum signal quality requirements: Wi-Fi: -60 dBm; GSM: -85 dBm.
• User Interface:
  • Built-in OLED display.
  • RFID card reader.
  • Control buttons.
• Energy Monitoring:
  • Built-in three-phase energy meter.
  • Optionally available certified Enelion MID meter.
• Protection and Safety:
  • Built-in residual current monitoring device (RCM B).
  • Optionally available RCD A or RCD B.
  • Impact protection rating: IK10.
  • Dust and water protection rating: IP54.
• Materials and Construction:
  • Housing made of anodized aluminum, resistant to atmospheric conditions.
  • Available in black and silver color options.
  • Modular design allows module replacement within 2 minutes.
• Dimensions:
  • Height: 1310 mm.
  • Diameter: 250 mm.
• Additional Features:
  • Dynamic load balancing (DLB) for optimal power distribution between charging stations.
  • Pre-fabricated foundation for quick device installation.
